API 6A Anti Corrosion Fracturing Christmas Tree
Features Gallery Product Description Request A Quote
Features
Specifications
NAME: Wellhead And Christmas Tree
Bore Size: 4 1/16" - 7 1/16"
Working Pressure: 2000psi - 20000psi
Advantage: Resistance H2S, Anti-corrosion
Standard: API Spec 6A, NACE M0175
Material Grade: AA-HH
Temperature Class: -46~250℃
Highlight:

Fracturing Christmas Tree

,

Anti Corrosion Christmas Tree

,

API 6A Christmas Tree

Basic Infomation
Place of Origin: China
Brand Name: Jianhu Hongda
Certification: API 6A
Model Number: 4 1/16" - 7 1/16"
Payment & Shipping Terms
Packaging Details: wooden case
Delivery Time: 10-20 DAYS
Payment Terms: T/T, L/C
Supply Ability: 500 sets per 1 month
Product Description

Production Description:





Wellhead equipment and oil (gas) tree equipment are important equipment for oil and gas exploitation. Our wellhead equipment and gas tree equipment are designed and manufactured in strict accordance with the latest version of API 6A standard, GB/T22513 specification and NACE MR-0175 standard. The products are mainly composed of casing head assembly, casing four-way assembly, tubing four-way assembly and gas tree assembly. The company can produce conventional oil (gas) wellhead devices, and can also design and manufacture wellhead devices for special purposes and special structures such as oil testing and fracturing according to user requirements.



Fracturing Christmas Tree is a specialized device used for fracturing operations, used to control and monitor the injection and production of liquids and pressures during the fracturing process. It is usually installed on the upper part of the wellhead and connected to the head of the wellhead.
Fracturing oil trees have the following main components and functions:
Main structure: The main structure of a fracturing oil production tree is usually made of metal, including the tree body and tree cap. The tree is a tubular structure connected to the head of the wellhead, providing support and fixing the fracturing device. The tree cap is the top part of the tree body, used for installing and operating control valves and other key components.
Valves and control devices: Multiple valves and control devices are equipped on the fracturing production tree to control the flow and pressure of liquids and gases. Common valves include ball valves, gate valves, and throttle valves, which can open, close, or regulate flow to achieve control and monitoring of the fracturing process.
Fluid connection port: There are multiple connection ports on the fracturing production tree, used to connect pipelines for injecting and producing fluids. These connection ports usually include injection ports, production outlets, pressure monitoring ports, and flow meter interfaces for liquid injection and production, as well as monitoring parameters such as pressure and flow.
Pressure monitoring and control system: Pressure sensors and monitoring equipment are installed on the fracturing production tree for real-time monitoring of pressure changes during the fracturing process. These devices can provide critical data to assist operators in monitoring job status, ensuring safe and effective operations.
Safety devices: Fracturing oil trees may also include safety devices, such as safety valves and rupture discs, to protect the device and wellhead from the impact of high pressure or other abnormal situations.
The design and selection of fracturing oil trees depend on specific fracturing operation requirements and wellhead conditions. They need to meet relevant safety standards and regulations, and undergo strict testing and verification to ensure reliability and safety in fracturing operations. The correct use and maintenance of fracturing oil trees are crucial for achieving efficient fracturing operations and oil and gas production.



The company provides a complete range of API 6A standard requirements of wellhead equipment and oil (gas) tree products, including diameter 4 1/16in ~ 7 1/16in, working pressure 2000psi ~ 15000psi, temperature range L ~ U, material level AA ~ HH, product specification level PSL1 ~ PSL3G, Performance requirements PR1 to PR2.
