15000 Psi Rotary Coflexip Hose 3 Inch Mud Pump Hose
Rotary Coflexip Hose assembly often carries high-pressure drilling liquids from the top of the mud standpipe to the rotary swivel. Rotary hose, especially slim hose, is often used on small or medium-sized drilling rigs such as water well operations, water well, water well core drill, and other applications. Rotary Coflexip Hose can carry mud or air.
Specification and basic parameters for Rotary Coflexip Hose
| Inter dia.in mm(in) | Rated operating pressure in MPa(psi) | Test pressure in MPa(psi) | Min. burst pressure in MPa(psi) | Min. bending radius (mm) |
| 50.8(2) |
35.0(5 000) |
70.0(10 000) |
105.0(15 000) |
900 |
| 64(2 1/2) | 1000 | |||
| 76.2(3) | 1000 | |||
| 89(3 1/2) | 1100 | |||
| 101.6(4) | 1200 | |||
| 50.8(2) | 70.0(10 000) | 105.0(15 000) | 157.5(22 500) | 1000 |
| 63.5(2 1/2) | 1100 | |||
| 76.2(3) | 1150 | |||
| 89(3 1/2) | 1200 | |||
| 101.6(4) | 1250 | |||
| 50.8(2) |
105.0(15000) |
157.5(22500) |
236.25(33750) |
1000 |
| 63.5(2 1/2) | 1150 | |||
| 76.2(3) | 1200 | |||
| 50.8(2) |
138.0(20000) |
207.0(30000) |
310.0(45000) |
900 |
| 64(2 1/2) | 1100 | |||
| 76.2(3) | 1200 |
The information you may like to know before Payment:
1. Methods of Payment:
T/T (Telegraphic Transfer) or L/C at sight
2. Shipping way
Sample order: we suggest Courier express like DHL/UPS/TNT/FEDEX or by air
Bulk order: we suggest by air or by sea.
3. Quality Control
We have our own experienced QC.
There will be strict inspection and testing for every order before shipping out.
