1" 5000psi Heat Insulation High Pressure Hydraulic Hose ISO For Drilling API 16D Armored Fire Resistant Hose

1" 5000psi Heat Insulation High Pressure Hydraulic Hose ISO For Drilling API 16D Armored Fire Resistant Hose
1" 5000psi Heat Insulation High Pressure Hydraulic Hose ISO For Drilling API 16D Armored Fire Resistant Hose

Large Image :  1" 5000psi Heat Insulation High Pressure Hydraulic Hose ISO For Drilling API 16D Armored Fire Resistant Hose

Product Details:
Place of Origin: China
Brand Name: Hebi Jingbo
Certification: API 16D
Model Number: 1"-5000psi
Payment & Shipping Terms:
Minimum Order Quantity: 1 pcs
Price: USD 50-500 per set
Packaging Details: Iron Case
Delivery Time: 7 work days
Payment Terms: T/T
Supply Ability: 500 sets per 1 month
Contact Now

1" 5000psi Heat Insulation High Pressure Hydraulic Hose ISO For Drilling API 16D Armored Fire Resistant Hose

Description
Name: 1 Inch High Pressure Fire Resistant Hose Advantage: Armored, Double Hook Stainless Steel Jacket Type
Connection: Fig 1502 Hammer Union Inner Dia: 1 Inch
Applicable Standard: API Spec 16D Usage: Hydraulic Control Of The BOP
Working Pressure: 2000psi-15000psi
Highlight:

High Pressure Hydraulic Hose ISO

,

Heat Insulation High Pressure Hydraulic Hose

,

Heat Insulation Hydraulic Hose

1" 5000psi Heat Insulation High Pressure Hydraulic Hose ISO For Drilling API 16D Armored Fire Resistant Hose
Product Overview
The 1" 5000 PSI Heat Insulation High Pressure Hydraulic Hose is engineered to meet API 16D and ISO standards, providing maximum safety and durability in drilling operations. Constructed with a fire-resistant armored design, the hose maintains structural integrity and hydraulic reliability even in extreme temperature and flame exposure scenarios. Its thermal insulation layer ensures stable fluid performance under continuous high-pressure conditions, while the compact 1-inch bore is optimized for precise control functions. This hose is ideally suited for BOP control systems and other hydraulic circuits where compliance, fire resistance, and operational safety are mandatory.
Key Features
  • High pressure resistance (up to 5000 psi)
  • Flame retardant and fire-resistant performance
  • Flexible structure with multi-layer reinforcement
  • Resistant to oil, heat, and abrasion
  • Suitable for both onshore and offshore drilling rigs
Technical Specifications
Nominal Bore (in) Outer Diameter (in) Working Pressure (psi) Test Pressure (psi) Minimum Burst Pressure (psi) Minimum Bending Radius (in) End Connection Operating Time (Normal / Emergency)
3/4" (19 mm) 1.73 - 1.97 5,000 7,500 15,000 11 NPT / LP 5 min / 25 min
7/8" (22 mm) 1.85 - 2.09 5,000 7,500 15,000 12.6 NPT / LP 5 min / 25 min
1" (25 mm) 1.97 - 2.20 5,000 7,500 15,000 14.2 NPT / LP 5 min / 25 min
1 1/4" (31.5 mm) 2.20 - 2.44 5,000 7,500 15,000 18.1 NPT / LP 5 min / 25 min
1 1/2" (38 mm) 2.48 - 2.72 5,000 7,500 15,000 22 NPT / LP 5 min / 25 min
Applications
  • Hydraulic control for BOP stacks
  • Drilling rigs (onshore / offshore)
  • Emergency well control systems
  • High-risk oilfield environments requiring flame resistance
Our Advantages
  • Proven experience in supplying BOP control hoses for major drilling contractors
  • Customizable hose length, pressure rating, and connections
  • Global logistics support and fast delivery
  • API / ISO certified production facilities
