Product Details:
|
Name: | BOP Control Hose/drilling Hose | Size: | 1" |
---|---|---|---|
Working Pressure: | 10000psi | API: | API 16D Monogrammed |
Cover: | Armored With 304 Stainless | Brand: | Shandong Longkou |
Highlight: | Armored BOP Control Hose,10000psi Armored Hose,Fire Resistance BOP Control Hose |
Nominal Bore (in) | Outer Diameter (in) | Working Pressure (psi) | Test Pressure (psi) | Minimum Burst Pressure (psi) | Minimum Bending Radius (in) | End Connection | Operating Time (Normal / Emergency) |
---|---|---|---|---|---|---|---|
3/4" (19 mm) | 1.73 - 1.97 | 5,000 | 7,500 | 15,000 | 11 | NPT / LP | 5 min / 25 min |
7/8" (22 mm) | 1.85 - 2.09 | 5,000 | 7,500 | 15,000 | 12.6 | NPT / LP | 5 min / 25 min |
1" (25 mm) | 1.97 - 2.20 | 5,000 | 7,500 | 15,000 | 14.2 | NPT / LP | 5 min / 25 min |
1 1/4" (31.5 mm) | 2.20 - 2.44 | 5,000 | 7,500 | 15,000 | 18.1 | NPT / LP | 5 min / 25 min |
1 1/2" (38 mm) | 2.48 - 2.72 | 5,000 | 7,500 | 15,000 | 22 | NPT / LP | 5 min / 25 min |
