Name: Triplex F500 High Pressure Mud Pump API 7K 165stoke/min For Deep Drilling
Brand: RS
SKU: F500
Price: 1000 USD
Availability: InStock
Rating: 5 (116 reviews)

Features Gallery Product Description Request A Quote

Features

Specifications

Name: F 500 Mud Pump

Rated Input Power: 368kw

Rated Frequency Of Stroke: 165stoke/min（165SPM）

Stoke: 7 1/2”

Ratio Of Gear: 4.286:1

Maximum Working Pressure: 5000psi

Maximum Diameter Of The Cylinder Liner: 6 3/4"

Usage: Deep Drilling

Highlight:

Drilling High Pressure Pump API 7K

Triplex F500 Mud Pump

Deep Drilling Mud Pump

Basic Infomation

Place of Origin: China

Brand Name: RS

Certification: API 7K

Model Number: F500

Payment & Shipping Terms

Packaging Details: Iron case

Delivery Time: 7 days

Payment Terms: L/C, T/T

Supply Ability: 10 SET per month

Gallery

Triplex F500 High Pressure Mud Pump API 7K 165stoke/min For Deep Drilling

Product Description

Triplex F 500 Mud Pump API-7K For Deep Drilling

F 500 Mud Pump with Multiple liner sizes allow pressures and volumes to handle circulation requirements in deep drilling applications.

F 500 Mud Pump Performance parameters

RS-F500 (the British system) Relational Diagram of Dill Pump Displacement and Pressure
Diameter of the cylinder jacket		in		6 3/4		6 1/2	6	5 1/2	5	4 1/2	4
Output pressure		MPa		9.2		10	11.7	13.9	16.8	20.8	26.3
Output pressure		psi		1315		1430	1670	1985	2400	2970	3760
Frequency of the stroke	Input power			Displacement L/s(Litre /second)
Stroke/min	kW		Horsepower	Displacement L/s(Litre /second)
165	368		500	36.2	33.6		28.6	24	19.9	16.1	12.7
150	334.5		455	32.9	30.55		26	21.8	18.1	14.64	11.55
140	312.2		424	30.72	28.51		24.27	20.36	16.88	13.66	10.78
130	289.9		394	28.52	26.47		22.53	18.91	15.68	12.68	10.01
120	267.6		364	26.33	24.44		20.8	17.45	14.47	11.71	9.24
110	245.3		333	24.1	22.4		19.07	16	13.27	10.73	8.46
1	2.23		3.03	0.219	0.204		0.173	0.145	0.121	0.098	0.077
Set Mechanical efficiency η=90%,Block coefficient α=100%, volumetric efficiency= 100%

Technical specification

parameters	Model of the dill pump
parameters	RS-F500
Rated input power	368kw (500HP)
Rated frequency of stroke	165stoke/min(165SPM)
Stoke	190.5mm(7 1/2”)
Ratio of gear	4.286:1
Maximum working pressure	34.5Mpa(5000psi)
Cage	API #5
Maximum diameter of the cylinder liner	6 3/4″
Maximum pumping pressure of the cylinder liner	9.2MPa
Suction pipe	203.2mm(8”)
Outlet pipe	4” flange(5000psi)
Pinion shaft diameter	139.7mm(5 1/2”)
Key	31.75x31.75 mm (1 1/4x1 1/4) ″
External Dimensions (main machine)	3639X2369X2315
Weight (main machine)	9543kg

Drawing of F 500 Mud Pump :

Triplex F500 High Pressure Mud Pump API 7K 165stoke/min For Deep Drilling 0

Triplex F500 High Pressure Mud Pump API 7K 165stoke/min For Deep Drilling 1
