F500 Oilwell Triplex Pumps Oil Well Drilling Plunger Pump
Introduction
F500 Oilwell Triplex Pumps equipment has two surfaces that can bear high strength to ensure the high efficiency of the operation.
Forced lubrication combined with splash lubrication to make the lubrication effect perfect;
The performance of F500 Oilwell Triplex Pumps was greatly improved by the durable fluid end; and examination, mud pump repair, and mud pump maintenance are easier to make due to their independent structure.
Parameters of F500 Oilwell Triplex Pumps
Liner Size | in | 6 3/4 |
6 1/2
|
6 | 5 1/2 | 5 | 4 1/2 | 4 |
3 1/2
|
Discharge Pressure | Mpa |
9.2
|
10
|
11.7
|
13.9
|
16.8
|
20.8
|
26.3
|
34.5
|
psi |
1334
|
1450
|
1670
|
2016
|
2400
|
3016
|
3814
|
5000
|
|
Stroke per Minute (SPM) |
Power KW(HP) |
Displacement L/s(GPM) | |||||||
170
|
384
(515)
|
37.29
(591.0)
|
34.62
(548.7)
|
29.46
(466.9)
|
24.72
(391.8)
|
20.50
(324.9)
|
16.59
(262.9)
|
13.08
(207.3)
|
10.05
(159.2)
|
*165 |
*373
(500)
|
36.2
(573.7)
|
33.6
(532.5)
|
28.6
(453.3)
|
24
(380.4)
|
19.9
(315.4)
|
16.1
(255.)
|
12.7
(201.2)
|
9.75
(154.5)
|
150 |
339.4
(455)
|
32.9
(521.4)
|
30.55
(484.2)
|
26
(412.1)
|
21.8
(345.5)
|
18.1
(286.8)
|
14.64
(232.0)
|
11.55
(183.0)
|
8.86
(140.4)
|
140 |
316.5
(424)
|
30.72
(486.9)
|
28.51
(451.8)
|
24.27
(384.6)
|
20.36
(322.7)
|
16.88
(267.5)
|
13.66
(216.5)
|
10.78
(170.8)
|
8.27
(131.0)
|
130 |
293.9
(394)
|
28.52
(452.0)
|
26.47
(419.5)
|
22.53
(357.1)
|
18.91
(299.7)
|
15.68
(248.5)
|
12.68
(200.9)
|
10.01
(158.6)
|
8.27
(131.0)
|
120 |
271.2
(364)
|
26.33
(417.3)
|
24.44
(387.3)
|
20.8
(329.6)
|
17.45
(276.5)
|
14.47
(229.3)
|
11.71
(185.6)
|
9.24
(146.4)
|
7.09
(112.3)
|
110 |
248.7
(333)
|
24.1
(381.9)
|
22.4
(355.0)
|
19.07
(302.2)
|
16
(253.6)
|
13.27
(210.3)
|
10.73
(170.0)
|
8.46
(134.0)
|
6.5
(103.0)
|
1 |
2.261
(3.03)
|
0.219
(3.47)
|
0.204
(3.23)
|
0.173
(2.74)
|
0.145
(2.29)
|
0.121
(1.91)
|
0.098
(1.55)
|
0.077
(1.22)
|
0.059
(0.93)
|
--Performance data are calculated by 90% mechanical efficiency and 100% volumetric efficiency. | |||||||||
--The * present the recommendatory SPM and input power when the mud pump runs continuously. |
F500 Oilwell Triplex Pumps Specification :
Rated input Power : 373 kW(500 HP)
Stroke Per Minute : 165 SPM
Stroke Length: 190.5 mm (7 1/2")
Gear Ratio: 4.286:1
Max. Working Pressure : 34.5 MPa (5000 psi)
Valve : API#5
Max.Liner Size : 170 mm (6 3/4")
Suction Inlet Flange : 203.2 mm (8") flange
Discharge Outlet Flange : 101.6 mm (4") flange,34.5 MPa (5000 psi)
Overall Dimension (L×W×H):3639×2369×2315 mm3(11.94×7.77×7.6 ft3)Approx Weight : 9543 kg (21039 lb)
