API 7K Triplex F800 Oil Rig Mud Pump Flange 5-1/8" 5000 Psi 150 Strokes/Min

Large Image : API 7K Triplex F800 Oil Rig Mud Pump Flange 5-1/8" 5000 Psi 150 Strokes/Min

Product Details:

Place of Origin:	China
Brand Name:	RS
Certification:	API 7K
Model Number:	F 800 Mud Pump

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	10000USD-15000USD
Packaging Details:	Iron case
Delivery Time:	7 days
Payment Terms:	L/C, T/T
Supply Ability:	10 SET per month

Contact Now

API 7K Triplex F800 Oil Rig Mud Pump Flange 5-1/8" 5000 Psi 150 Strokes/Min

Description

Name:	F 800 Mud Pump	Rated Input Power:	590kw (800HP)
Rated Frequency Of Stroke:	150 Strokes/Min (150SPM)	Stroke:	9″
Gear Ratio:	4.185：1	Pressure:	5000psi
Max. Cylinder Liner Diameter:	170mm	Certificate:	API 7K
Highlight:	Flange Oil Rig Mud Pump , F800 Oil Rig Mud Pump , 5000 Psi Oil Rig Pump

Triplex F 800 Mud Pump 5-1/8" 5,000 Psi Flange

The F 800 mud pump for oil drilling boasts a solid and compact structure, small volume, and reliable performance. It can meet drilling requirements for high pressure and large displacements, whether on land or offshore.

Technical Specification:

Parameter	Pump Model
Parameter	RS-F1000	RS-F800
Rated Input Power	735kW(1000HP)	590kW(800HP)
Rated Frequency of Stroke	140 Strokes/Min (140SPM)	150 Strokes/Min (150SPM)
Stroke	254mm(10″)	229mm(9″)
Gear Ratio	4.207:1	4.185:1
Max. Operating Pressure	34.5MPa	34.5MPa
Valve Chamber	API#6	API# 6
Max. Cylinder Liner Diameter	170mm	170mm
Max. Cylinder Liner Pump Pressure	16.4MPa (2410psi)	13.6MPa (1954psi)
Suction Pipe Orifice	305mm(12″)	254mm (10″) Flange
Discharge Pipe Orifice	5 1/8″5000psi Flange	5 1/8″5000psi Flange
Pinion Shaft Diameter	196.9mm(7 3/4″)	177.8mm(7″)
Key	50.8ⅹ50.8mm(2″ⅹ2″)	44.4x44.45mm(1 3/4x1 3/4″)
Overall Dimension (Main Frame)	4267X2350X1862mm	3963X2000X1694mm
Weight (Main Frame)	18642kg	14000kg

RS-F800 Drilling Pump Displacement and Pressure Relation Form
Cylinder Liner Diameter		mm	170	160	150	140	130	120	110	100
Discharge Pressure		MPa	13.6	15.4	17.5	20.1	23.3	27.3	32.5	34.5
Discharge Pressure		psi	1971	2232	2536	2913	3377	3957	4710	5000
Frequency of Stroke	Input Power		Displacement L/s
Strokes/Min	KW	HP	Displacement L/s
160	636	853	41.51	36.77	32.32	28.15	24.27	20.68	17.38	14.36
*150	*588	800	38.92	34.47	30.30	26.39	22.76	19.39	16.29	13.47
140	549	747	36.32	32.17	28.28	24.63	21.24	18.10	15.21	12.57
130	510	693	33.73	29.88	26.26	22.87	19.72	16.81	14.12	11.67
120	470	640	31.13	27.58	24.24	21.11	18.21	15.51	13.03	10.77
110	431	587	28.54	25.28	22.22	19.35	16.69	14.22	11.95	9.87
1	3.92	5.33	0.259	0.230	0.202	0.176	0.151	0.129	0.108	0.090
Taking mechanical efficiency η=90%, coefficient of admission α=100% and volume efficiency 100%; Input power at recommended number of strokes and continuous operation

Drawing:

API 7K Triplex F800 Oil Rig Mud Pump Flange 5-1/8" 5000 Psi 150 Strokes/Min 0
